Model: Amprobe HD160C Heavy Duty TRMS Multimeter with Temperature

The Amprobe HD160C Heavy Duty TRMS Multimeter with Temperature is intended for professional use in snappish environments. It's made using waterproof construction to prevent dirt, grime, and moisture from entering the deed and causing inaccurate readings or damaging shorts.

Built taking into consideration tough, a blaze-retardant thermoplastic that is resistant to grease and chemical spills and once surprise-mounted components that are slip-resistant to at least 8 feet, the Amprobe HD160C is unusually rugged and obedient. It has a lengthy voltage measurement expertise of 1500 V DC and 1000 V AC, unmatched by any accessory extraction of digital multimeters. The outstretched voltage ranges can withstand transients taking place to 12 kV, and it plus proceedings temperature. Amprobe is a sister concern of fluke corporation, Fluke Bangladesh is a distributor of fluke in Bangladesh. So all of the instrument both of them are very trusted and reliable. You may choose any type of Electrical tools that is available at Iconic Engineering.

Specifications: Amprobe HD160C Heavy Duty TRMS Multimeter with Temperature

FEATURE HD110C HD160C
DC Voltage 200.0 mV, 2.000 V, 20.00 V, 200.0 V, 1500 V 1000.0 mV, 10.000 V, 100.00 V, 1500.0 V
AC Voltage 200.0 mV, 2.000 V, 20.00 V, 200.0 V, 1000 V 1000.0 mV, 10.000 V, 100.00 V, 1000.0 V
Current AC/DC 200.0 µA, 2.000 mA, 20.00 mA, 200.0 mA, 2 A 100.00 µA, 1000.0 µA, 10.000 mA, 100.00 mA, 400.0 mA, 2.000 A
Resistance 200.0 O, 2.000 kO, 20.00 kO, 200.0 kO, 2.000 MO, 20.00 MO 1000.0 O, 10.00 kO, 100.00 kO, 1000.0 kO, 10.000 MO, 40.00 MO
Diode
Continuity
Frequency 100.00 Hz, 1000.0 Hz, 10.000 kHz, 100.00 kHz, 1000.0 kHz, 10.000 M Hz
Capacitance 40.00 nF, 400.0 nF, 4.000 µF, 40.00 µF, 400.0 µF
Temperature -4 °F → 2372 °F (-20 °C → 1300°C)
True-rms
Specifications
DC Volts range: 200 mV, 2 V, 20 V, 200 V, 1500 V
DC Volts resolution: 0.1 mV
DC Volts accuracy: All ranges ±(0.1 % rdg+2 dgts)
DC Volts input impedance: 10 MO
DC Volts OL protection: >1500 V DC/1000 V AC rms
DC Volts transient protection: >12 kV impulse (1.2 µS/50 µS) based on EN 61010-1:2001 impulse requirement for at CAT IV 1000 V product. This product should not be used in installations where transients exceed 12 kV
AC Volts (45 Hz to 2 kHz) ranges: 200 mV, 2 V, 20 V, 200 V, 1000 V
AC Volts (45 Hz to 2 kHz) resolution: 0.1 mV
AC Volts (45 Hz to 2 kHz) accuracy: 200 mV to 200 V (45-500 Hz) ±(0.8 % rdg+4 dgts),
AC Volts (45 Hz to 2 kHz) accuracy: 200 mV to 200 V (500 Hz-2 kHz) ±(1.5 % rdg+5 dgts)
AC Volts (45 Hz to 2 kHz) accuracy: 1000 V (50-60 Hz) ±(0.8 % rdg+4 dgts)
AC Volts (45 Hz to 2 kHz) accuracy: 1000 V (60-500 Hz) ±(1.5 % rdg+5 dgts)
AC Volts (45 Hz to 2 kHz) input impedance: 10 MO
AC Volts (45 Hz to 2 kHz) OL protection: 1500 V DC/1000 V AC rms
AC Volts (45 Hz to 2 kHz) transient protection: 12 kV impulse (1.2 µS/50 µS) based on EN 61010-1:2001 impulse requirement for at CAT IV 1000 V product. This product should not be used in installations where transients exceed 12 kV.
DC Current range: 200 µA, 2 mA, 20 mA, 200 mA, 2 A
DC Current resolution: 0.1 µA
DC Current accuracy: 200 µA to 20 mA ±(0.5 % rdg+2 dgts)
DC Current accuracy: 200 mA to 2 A ±(1.0 % rdg+2 dgts)

Key Features: Amprobe HD160C Heavy Duty TRMS Multimeter with Temperature

  • Highest voltage capability, measuring to 1500 V DC and 1000 V AC
  • Suitable for testing Solar installations
  • Special sealing for environment and water resistance: IP67 rated
  • Constructed with drop-resistant housing and PCB mounting
  • Measures capacitance, temperature, and frequency
  • Superior 10,000 count resolution with bar graph
  • Magne-Grip™ holster frees both hands for work
  • Digi-Glo™ bright backlight
  • Display 4 digit LCD, 9999 counts, with annunciators, menu features, and 41 segment bar graph
  • Polarity indication automatic
  • Input overload indication OL, -OL
  • Auto power-down
